DC Isolator 32 amp 4 pole

N-Line DC isolator

Enclosed DC Isolating Switch IP66NW 4 Pole 1500V DC 32A
This enclosed DC isolating switch has been designed, engineered and developed for 1~20kW residential and commercial rooftop solar applications. This DC isolating switch provides a safe means of isolating your PV array during installation or maintenance while keeping you and your solar system from harms way.

For all installations up to 1500V DC, it is fully compliant to AS 60947.3 and AS/NZS IEC 60947.1. In addition, the polycarbonate enclosure consists of an injected TPE gasket for IP66NW protection - ensuring best protection against damaging dust and moisture ingress.

Features and Benefits
32 A, 1500 V Enclosed DC switch
Fully compliant with AS60947.3:2018 suitable to be used throughout Australia and New Zealand
Robust IP66NW polycarbonate enclosure ensured protection against damaging moisture ingress and UV exposure
Superior temperature performance, conforming to AS5033:2018
Long lasting service life and reliable switching
Arcing time <3 ms utmost safety and protection ensuring seamless isolation
4 x M25 top and bottom threaded entries with injected TPE seal
2 x M25 rear knockouts for cable entries
Pre-fitted pressure compensation valve as standard
Provision for external mounting
Padlockable in OFF position
Accessory kit included
Specifications
IP Rating IP66NW
Number of Poles 4
Operating Temperature, Max 85 °C max
Operating Temperature, Min -40 °C min
Ui, Rated Insulation Voltage, 1500 V DC
Wire / Conductor Size, Max16 mm² max
Wire / Conductor Size, Min4 mm² min
Included Accessories
M25 to M12 Reducer x 1
Bridging Links x 2
Wall Mounting Bracket x 2
Mounting Bracket Screws x 4
Screw Caps x4
Base Caps x 6

Length (mm) 180

Width (mm) 99
Depth (mm) 107
